Elcometer

Elcometer 480 Glossmeter - Model T Dual

Elcometer 480 Glossmeter - Model T Dual Alternative View #2

Add to Cart

$3,099.00

Buy now and pay over time with PayPal Credit. Learn more

Please note: this item ships directly from the manufacturer in 2-3 business days

Please note: discount codes do not apply to this item

Available Sizes

Model B
$2,389.00

Model T Single
$2,699.00

Model T Dual
$3,099.00

Model T Triple
$4,099.00

Product Information

Why guess when you can know how much gloss you have?
Accurately measures up to 3 gloss angles at a time
Up to 10 readings per second
Product Codes: J480B-6, J480T-6, J480T-26, J480T-268
Read full description

Product Description

The Elcometer 480 Glossmeter allows you to actually measure the amount of gloss your paintwork is showing off! After you put in the hours to polish and protect your paint, often times the only real measure of gloss you receive is from your own eyes. If the paint looks fantastic, you almost always can tell, but what if there was a way to actually measure the amount of gloss? With the Elcometer 480 Glossmeter you will know exactly how much gloss you have instead of guessing! Using state of the art design and manufacturing techniques, the Elcometer 480 provides high-quality features, functionality and reliably for measuring & recording Gloss, % Reflectance & Haze on any material, including paint, plastic, ceramic or metal. What Elcometer calls, rapid LED technology, accurately measures up to 3 gloss angles at the same time at a rate of 10 readings per second. These gloss measurements are easily viewed on the large beautiful screen and can be instantly transferred from the meter to PC, iPhone, Android or other mobile devices via USB or Bluetooth. Take a look at the various technical specifications directly from Elcometer below. Stop guessing at the amount of gloss on your vehicle, measure it with the Elcometer 480 Glossmeter!

Technical Specifications:

Model B:

Measurement geometries: 60 Degrees
Measurement units: GU
Fast, accurate reading rate
Repeatable & reproducible measurements
Easy to use menu structure; in 30+ languages
Tough, impact, waterproof & dust resistant
Scratch & solvent resistant colour display; 2.4" (6cm) TFT
Rotating display: auto, 0 Degrees, 180 Degrees
Ambient light sensor; with adjustable auto brightness
Data output: USB live readings
USB & battery powered
Calibration Certificate
Manual gauge calibration
On screen statistics - user selectable: Number of readings, Mean (average), Standard deviation
Measurement modes: Standard Mode
Gauge auto diagnostics
Display modes; user selectable - Readings; gloss, % reflectance, haze, Selected statistics
Delete last reading
2 year manufacturer extended warranty
Display information: 2.4" (6cm) QVGA colour TFT display, 320 x 240 pixels
Power: USB (via PC) or 2 x AA batteries (~50,000 readings)
Measurement Dimensions: 20 Degrees: 10 x 10mm; 60 Degrees: 8 x 16mm; 85 Degrees: 4 x 55mm
Measurement Range: 20 Degrees: 0 - 2,000GU; 60 Degrees: 0 - 1,000GU; 85 Degrees:0 - 160GU
Repeatability: +- 0.1GU (0 - 10GU); +- 0.2GU (10 - 100GU); +- 0.2%: 100 - 2000GU
Reproducibility: +- 0.2GU (0 - 10GU); +- 0.5GU (10 - 100GU); +- 0.5% 100 - 2000GU
Resolution: Gloss: 0.1 GU (0 - 100GU); 1 GU (>100GU) - % Reflectance: 0.01% (0 - 10GU); 0.1% (10 - 100GU) - Haze: 0.1 HU (0 - 100HU); 1 HU (>100HU)
Operating Temperature: -10 Degrees C to 50 Degrees C (14 to 122 Degrees F); Relative Humidity: 0 - 85%RH
Dimensions: (H x W x D) 68 x 155 x 50mm (2.68" x 6.10" x 1.97")
Weight: 534g (1lb 3oz) [including batteries]

Model T (Single, Dual & Triple):

Measurement geometries: 60 Degrees (Single), 20 Degrees and 60 Degress (Dual), 20 Degrees, 60 Degrees and 85 Degrees (Triple)
Measurement units: GU
Fast, accurate reading rate
Repeatable & reproducible measurements
Easy to use menu structure; in 30+ languages
Tough, impact, waterproof & dust resistant
Scratch & solvent resistant colour display; 2.4" (6cm) TFT
Rotating display: auto, 0 Degrees, 180 Degrees
Ambient light sensor; with adjustable auto brightness
Data output: USB live readings - USB batch download - Bluetooth: to PC, iOS or Android mobile devices
USB & battery powered
Calibration Certificate
Manual gauge calibration
Auto gauge calibration; via RFID tagging of integrated calibration tile#
On screen statistics - user selectable: Number of readings, Mean (average), Standard deviation
Highest reading, Lowest reading, Range: Coefficient of variation, Nominal value, High Limit value, Low Limit value, Number above high limit, Number below low limit
Measurement modes: Standard Mode - Auto Repeat Mode; programmable 10-180 readings per minute - Scan Mode; 10 readings per second - Differential Mode with Pass/ Fail mode
Limit Standards; up to 40 programmable standards - Gauge & batch specific standard limits
Gauge memory 40,000 readings in up to 2,500 batches
Alpha-numeric batch names
Fixed batch size mode
Date and time stamp
Gauge auto diagnostics
Display modes; user selectable - Readings; gloss, % reflectance, haze, Selected statistics - Live trend graph; last 20 readings - Scan bar - Readings & differential (with pass/fail)
Delete last reading
2 year manufacturer extended warranty
Display information: 2.4" (6cm) QVGA colour TFT display, 320 x 240 pixels
Power: USB (via PC) or 2 x AA batteries (~50,000 readings)
Measurement Dimensions: 20 Degrees: 10 x 10mm; 60 Degrees: 8 x 16mm; 85 Degrees: 4 x 55mm
Measurement Range: 20 Degrees: 0 - 2,000GU; 60 Degrees: 0 - 1,000GU; 85 Degrees:0 - 160GU
Repeatability: +- 0.1GU (0 - 10GU); +- 0.2GU (10 - 100GU); +- 0.2%: 100 - 2000GU
Reproducibility: +- 0.2GU (0 - 10GU); +- 0.5GU (10 - 100GU); +- 0.5% 100 - 2000GU
Resolution: Gloss: 0.1 GU (0 - 100GU); 1 GU (>100GU) - % Reflectance: 0.01% (0 - 10GU); 0.1% (10 - 100GU) - Haze: 0.1 HU (0 - 100HU); 1 HU (>100HU)
Operating Temperature: -10 Degrees C to 50 Degrees C (14 to 122 Degrees F); Relative Humidity: 0 - 85%RH
Dimensions: (H x W x D) 68 x 155 x 50mm (2.68" x 6.10" x 1.97")
Weight: 534g (1lb 3oz) [including batteries]

Includes

Glossmeter
Integrated calibration tile
Calibration certificates for gauge & calibration tile
2 x AA batteries
wrist strap
Operating instructions
Plastic carry case
ElcoMaster software (Model T)
USB cable (Model T)
